Specially developed for XR, XL, and LGP chassis
Excellent wear resistance and durability
Long service life under heavy working conditions
Stable performance for demanding applications
Wear Resistance: BERCO chain is equipped with highly wear-resistant components to achieve maximum service life in your application.
Lubricity: This product is lubricated and suitable for high and low temperature environments.
Temperature Adaptability: BERCO chain is designed for extreme applications and can adapt to temperatures ranging from -45°C to +50°C.
Product Applications:
BERCO chain is suitable for various fields such as mining excavators, bulldozers, construction excavators and bulldozers.
The products cover the mining, construction and utility fields, providing undercarriage systems and components for crawler machines from 50 tons to 400 tons.
| MAKER | MODEL | DESCRIPTION | PITCH | OUR P/NO. | BERCO No. |
| KOMATSU | PC60-3 | LINK(42L)12.3mm | 135 | KU001-W0-42 | KM906 |
| PC60-6, PC75 | LINK(39L)14.3mm | 154 | KU002-P0-39 | KM1686/3041 | |
| PC120-3 | LINK(43L) 14.3mm | 154 | KU003-P0-43 | KM965 | |
| PC100-5 | LINK(42L)16.3mm | 175 | KU004-P0-42 | KM1262 | |
| PC200-5/6 | LINK(45L)20.3mm | 190 | KU005-P1-45 | KM782 | |
| LINK(49L)None Seal | 190 | KU005-N1-49 | KM782UNS/49 | ||
| PC200-3 | LINK(46L)18.3mm | 190 | KU005-P0-44 | KM1170 | |
| LINK(46L)None Seal | 190 | KU005-N0-46 | |||
| PC300-3 | LINK(47L)20.0mm | 203 | KU007-P0-47 | KM959 | |
| LINK(47L)None Seal | 203 | KU007-N0-47 | KM959UNS/47 | ||
| PC300-5 | LINK(47L)22.0mm | 203 | KU007-P1-47 | KM1617 | |
| PC300-6 | LINK(48L) | 216 | KU012-P0-48 | KM2233 | |
| PC400-3 | LINK(53L)22.3mm | 216 | KU009-P2-53 | KM973 | |
| PC400-5 | LINK(49L)24.3mm | 216 | KU009-P1-49 | KM1402 | |
| PC400-6 | LINK(49L) | 229 | KU011-P0-49 | KM2489 | |
| PC650 | LINK(47L) | 260.4 | KM596 | ||
| PC1000-3 | LINK(51L) | 260 | |||
| PC1100-6/1250-7 | LINK948L) | 260 | |||
| CATERPILLAR | E70 | LINK(42L) | 135 | KU085-P0-42 | MT24/42 |
| E311 | LINK(41L) | 171.45 | KU061-P1-41 | CR4854/41 | |
| CAT213/215 | LINK(49L) | 171.45 | KU041-P0-49 | CR2849/49 | |
| E110 | LINK(43L) | 171.45 | KU121-P0-43 | CR1766/43 | |
| CAT225 | LINK(43L) | 171.1 | KU122-N0-43 | CR4858 | |
| CAT225B | LINK(46L) | 175.5 | KU042-P0-46 | CR5035 | |
| CAT225D | LINK(49L) 19.3mm | 190 | KU030-P2-49 | CR5011 | |
| CAT320 | LINK(45L) | 190 | KU030-P0-45 | CR5350/45 | |
| CAT325 | LINK(45L) | 203 | KU031-P0-45 | CR5489/45 | |
| CAT330 | LINK(45L) | 215.9 | KU032-P0-45 | CR5936/45 | |
| CAT235 | LINK(49L) | 215.9 | KU044-W1-49 | CR4235 | |
| HITACHI | EX40/45 | LINK(38L) | 135 | KU060-N0-38 | |
| EX60 | LINK(37L) | 154 | KU050-P0-37 | HT418 | |
| EX100 | LINK(41L) | 171.45 | KU061-P1-41 | CR4854 | |
| EX100M(EX150) | LINK(45L) | 171.45 | KU052-P0-45 | HT420 | |
| EX200-1 | LINK(48L) | 175.5 | KU053-P0-48 | HT17 | |
| EX200-3 | LINK(46L) | 190 | KU005-P0-46 | KM1170 | |
| EX300 | LINK(47L) | 203 | KU007-P0-47 | KM959 | |
| ZX330 | LINK(45L) | 216 | KU012-P0-45 | KM2233 | |
| EX400-1 | LINK(49L) | 216 | KU009-P5-49 | MT14A | |
| EX550 | LINK(53L) | 228 | |||
| EX700/750/800 | LINK(51L) | 260 | |||
| EX1100-3 | LINK(52L) | 260 | |||
| KOBELCO | SK60 | LINK(38L) | 154 | KU002-P0-38 | |
| SK120 | LINK(43L) | 171.1 | KU080-P0-43 | ||
| K907B | LINK(48L) | 175.4 | KU053-N0-48 | ||
| SK200 | LINK(49L) | 190 | KU030-N0-49 | ||
| SK300 | LINK(47L) | 203 | KU082-W0-47 | CR5060 | |
| SK480LC | LINK(50L) | 228 | SI1057 | ||
| KATO | HD770 | LINK(47L) | 175.5 | KU021-P1-47 | KM967 |
| DAEWOO | S50 | LINK(40L) | 135 | KU071-N0-40 | |
| S220 | LINK(52L) | 175.5 | KU053-P0-52 | HT17/52 | |
| S220-3 | LINK(49L) | 190 | KU005-P1-49 | KM782/49 | |
| S280 | LINK(47L) | 203 | KU007-P5-47 | KM959/47 | |
| SAMSUNG | MX55 | LINK(39L) | 135 | KU071-N0-39 | |
| (VOLVO) | MX135 | LINK(46L) | 171.45 | KU061-P1-46 | CR4854/46 |
| SE210 | LINK(54L) | 171.1 | KU063-N0-54 | CR2006/54 | |
| SE210-2 | LINK(45L) | 190 | KU005-P6-45 | KM782/45 | |
| SE280-2 | LINK(47L) | 203 | KU007-P0-47 | KM959/47 | |
| SE350 | LINK(48L) | 216 | MT14/48 | ||
| SE450 | LINK(52L) | 216 | |||
| HYUNDAI | R500 | LINK(40L) | 135 | KU060-N0-40 | |
| R1300-3 | LINK(46L) | 171.45 | KU061-P1-46 | CR4854/46 | |
| R2000 | LINK(54L) | 171.45 | KU063-N0-54 | CR2006/54 | |
| R210-7 | LINK(49L) | 190 | KU064-P0-49 | KM782/49 | |
| R280 | LINK(51L) | 203 | KU007-P0-51 | KM959/51 | |
| R290-7 | LINK(48L) | 216 | KU012-P0-48 | KM2233 | |
| R360 | LINK(51L) | 216 | |||
| R450 | LINK(53L) | 216 | |||
| FIAT | FIAT 25 | LINK(34L) | 125 | KU094-N0-34 | FT1335/34 |
| FL4 | LINK(35L) | 140 | KU089-N0-35 | FT1351/35 | |
| FL4 SPECIAL | LINK(35L) | 140 | KU090-N0-35 | ||
| FL6 | LINK(35L) | 160 | KU093-N0-35 | FT905 | |
| FIAT 7C/FL9 | LINK(45L) | 170 | KU096-N0-45 | FT1667/45 | |
| FH200 | LINK(48L) | 176 | KU078-N0-48 | FT2754/48 | |
| FH300 | LINK(47L) | 202.9 | KU079-N0-47 | FT2780/47 | |
| ETC. | BENFRA 4C/4CH | LINK(36L) | 140 | KU075-W0-36 | LA308 |
| HD11B | LINK(56L) | 177.8 | KU083-P0-56 | AC1967 | |
| LS4300Q | LINK(50L) | 203 | C8A0255 |
