The hydraulic track pin press is a pressing tool used to remove and installing the end bolt on track chains on excavators. The tool can be used in situ to save time. Just install the tool part by part in place, connect a hydraulic pump and go.
100T/200T Portable hydraulic track link pin press machine: this press is for removal and insertion of master pin and removal of sprocket for all type of Excavators&Dozers, and for earth moving /Mining equipments.
The track is also known as caterpillar, continuous track or tank tread for the removal or installation of the pins from the undercarriage tracks of excavators, bulldozers, tanks, tractors and similar track propelled machinery.
Portable hydraulic track press pusher (manual hydraulic or electric pump) is available for smaller machine tracks and larger fixed electrical machines are available for larger machinery tracks (suited for workshop).
| Type | Machine type | Fit for pitch (mm) | Mould | Fit machine | Efficiency |
|---|---|---|---|---|---|
| qty | Example of Komatsu | ||||
| Manual press link machine weight about 250Kgs | GT150-1 | 175,190 | 1 | PC100,PC200 | |
| GT150-2 | 175,190,203 | 2 | PC100,PC200, | about 15-20 mins | |
| PC300 | per link section | ||||
| GT150-3 | 175,190,203,216 | 3 | PC100,PC200, | ||
| PC300,PC400 | |||||
| GT200 | 175,190,203,216 228 | 4 | PC100,PC200, | ||
| PC300,PC400-6 | |||||
| GT200-1 | Only for 280 | 1 | PC600,D9,D10 | ||
| Manual & Electronic press link machine, weight about 300Kgs | GT150-1E | 175,190 | 1 | PC100,PC200, | |
| GT150-2E | 175,190,203 | 2 | PC300 | ||
| GT150-3E | 175,190,203,216 | 3 | PC100,PC200, | about 7-10mins | |
| GT200E | 175,190,203,216 228 | 4 | PC100,PC200, PC300,PC400-6 | per link section | |
| GT200-1E | Only 280 | 1 | PC600,D9,D10 |
For high-quality excavator track press and track pin press, trust XMGT, a professional supplier with 20 years of export experience in 128+ countries. We collaborate with BERCO and ITM, providing OEM undercarriage and G.E.T. parts to top brands like ITR. With 200+ product types and 5000+ specifications, we ensure reliability. Our warranty covers up to 12 months from the bill of lading date. Contact [email protected] for prices, discounts, and expert support—we’re ready to assist!
