| Brand | Model | Dimension(in,Tracl Width*Pitch*No.of link) | Width in (mm) | Length in (mm) | Pitch Length in | Tread Bar Qty | Guide Lug Qty | Driving type |
| CNH | Case STX Quadtrac/Axial Flow Combine | 30"*6"*42 | 30"(762) | 252"(6401) | 6" | 84 | 42 | Positive |
| CNH | Case STX Quadtrac/Axial Flow Combine | 36"*6"*42 | 36"(915) | 252"(6401) | 6" | 84 | 42 | Positive |
| CNH | 9300 Series | 30"*6"*39 | 30"(762) | 234"(5944) | 6" | 78 | 39 | Positive |
| CNH | 9301 Series | 36"*6"*39 | 36"(915) | 234"(5944) | 6" | 78 | 39 | Positive |
| CNH | Case Ste Quadtrac/MRowtrac.New Holland T8 SmartTrax | 18"*6"*44 | 18"(457) | 264"(6706) | 6" | 88 | 44 | Positive |
| CNH | Case Steiger/MagnumRowtrac,New Holland T8 SmartTrax | 24"*6"*44 | 24"(610) | 264"(6706) | 6" | 88 | 44 | Positive |
| CNH | Case Steiger/MagnumRowtrac,New HollanaT8 SmartTrax | 30"*6"*44 | 30"(762) | 264"(6706) | 6" | 88 | 44 | Positive |
| CNH | Case Axial FlowCombine/New Holland CR, CX Combine | 24"*6"*44 | 24"(610) | 264"(6706) | 6" | 88 | 44 | Positive |
| CNH | Case Axial Flow Combine/New Holland CR,CX Combine | 30"*6"*44 | 30"(762) | 264"(6706) | 6" | 88 | 44 | Positive |
| CNH | Case Axial Flow Combine/New Holland CR,CX Combine | 36"*6"*44 | 36"(915) | 264"(6706) | 6" | 88 | 44 | Positive |
| John Deere | 9RX Wide | 30"*6"*45 | 30"(762) | 264"(6706) | 6" | 88 | 45 | Positive |
| John Deere | 9RX Wide | 36"*6"*45 | 36"(915) | 270"(6858) | 6" | 90 | 45 | Positive |
| John Deere | 9RX Narrow | 18"*6"*45 | 18"(457) | 270"(6858) | 6" | 90 | 45 | Positive |
| John Deere | 9RX Narrow | 24"*6"*45 | 24"(610) | 270"(6858) | 6" | 70 | 45 | Positive |
| John Deere | 8RX Front | 18"*6"*35 | 18"(457) | 210"(5334) | 6" | 90 | 35 | Positive |
| John Deere | 8RX Front | 24"*6"*45 | 24"(610) | 270"(6858) | 6" | 90 | 45 | Positive |
| John Deere | 8RX Rear | 18"*6"*45 | 18"(457) | 270"(6858) | 6" | 90 | 45 | Positive |
| John Deere | 8RX Rear | 24"*6"*45 | 24"(610) | 270"(6858) | 6" | 90 | 45 | Positive |
| John Deere | 8RX Rear | 30"*6"*45 | 30"(762) | 270"(6858) | 6" | 90 | 45 | Positive |
| Versatile | Delta-Track | 30"*6"*42 | 30"(762) | 252"(6401) | 6" | 84 | 42 | Positive |
| Versatile | Delta-Track | 36"*6"*42 | 36"(915) | 252"(6401) | 6" | 84 | 42 | Positive |
| Brand | Model | Width in (mm) | Length in (mm) | Pitch Length in | Tread Bar Qty | Guide Lug Qty | Driving type |
| CAT Challenger | 35/45/55 | 18"(457) | 318"(8077) | 6" | 106 | 53 | Friction |
| 25"(635) | |||||||
| 30"(762) | |||||||
| CAT Challenger | 65/75/85/95 | 25"(635) | 342"(8687) | 6" | 114 | 57 | Friction |
| 30"(762) | |||||||
| 36"(915) | |||||||
| AGCO | MT700 Series (MT735/745/755/765/775) | 18"(457) | 348"(8839) | 6" | 116 | 58 | Friction |
| 25"(635) | |||||||
| 30"(762) | |||||||
| AGCO(FENDT) | AGCO MT700 Series(MT738/740/743)FENDT VARIO MT900 Series(938/940/943MT) | 18"(457) | 360"(9144) | 6" | 120 | 60 | Friction |
| 25"(635) | |||||||
| 30"(762) | |||||||
| AGCO | MT800 | 30"(762) | 390"(9906) | 6" | 130 | 65 | Friction |
| 36"(915) | |||||||
| John Deere | 8000T | 18"(457) | 324"(8230) | 6" | 108 | 54 | Friction |
| 25"(635) | |||||||
| 30"(762) | |||||||
| John Deere | 8RT | 18"(457) | 354"(8230) | 6" | 118 | 59 | Friction |
| 25"(635) | |||||||
| 30"(762) | |||||||
| John Deere | 9000T | 30"(762) | 378"(9601) | 6" | 126 | 63 | Friction |
| 36"(915) | |||||||
| John Deere | 9 RT(9430T/9530T/9630T and all 9RT model) | 30"(762) | 390"(9906) | 6" | 130 | 65 | Friction |
| 36"(915) | |||||||
| Claas | Terra Track | 25"(635) | 264"(6706) | 6" | 88 | 44 | Friction |
